Mimaki TS100-1600

Prix réduit$10,498.00 USD
When product is not in stock, usually the time to process is 5-7 days.


Entry-Level Price, Professional Results

The TS100-1600 is an affordable professional-grade sublimation roll-based printer. Consistently and expertly print highly detailed photographic quality graphics for small to large production runs.
  • Available in 64” with print speeds up to 753 Sq Ft/Hr.
  • Nozzle Check Unit (NCU) automatically monitors printhead performance and detects clogged nozzles.
  • Nozzle Recovery System (NRS) automatically substitutes unproductive nozzles, avoiding unnecessary downtime and poor image quality.
  • Sublimation ink colors: Blue, Magenta, Yellow, and Black.
  • The NEW Dot Adjustment System (DAS) automatically aligns to ensure consistent quality and repeatability.
  • NEW, easier-to-use RIP software, RasterLink7, reduces RIP time by 25%.
  • TxLink4 Lite supported more advanced workflows.


Our Core Technologies

img  Nozzle Check Unit
img Nozzle Recovery System
img Mimaki Bulk Ink System
img Uninterrupted Ink Supply System
img Mimaki Fine Diffusion
img Mimaki Circulation Technology
img Waveform Control
img Variable Dot Technology
img Mimaki Advanced Pass System



Two staggered, on-demand piezo heads

Print resolution

360 dpi, 600 dpi, 720 dpi, 900 dpi

Print speed (4 color mode)

753 SqFt/Hr

Maximum Print Area

63.3″ (1610.0 mm)

Maximum media width

63.8″ (1620 mm)

Maximum Media Thickness

up to 0.04″ (1 mm)

Maximum Media Weight⁨⁣

Up to 99.2 pounds (45 kg)

Ink Type

U.S. & Canada – Sb610 | Mexico, Central & South America- Sb610


1000 Base-T Ethernet cable or USB2.0 cable

Power Supply⁧⁢

AC100~120V/ 200~240V±10%, 50/60Hz±1Hz

Power Consumption

INLET 1/2: 1,440W or less (AC100V environment) 1,920W or less (AC200V environment)

Operational Environment

Temperature 20° – 30°C
Humidity: 35 – 65 % RH (Noncondensing)

Dimensions (W × D × H)

109.3 x 27.6 x 58.1″ (2,775 x 700 x 1,475 mm)


366lb (166kg)


VCCI class A, FCC class A,
CE Marking (EMC, Low voltage, Machinery directive, and RoHS),



Dye Sublimation Ink (SB610) Blue Magenta Yellow Black
1L Bottles I-SB610-BLT-BA-1-SW (E) I-SB610-MT-BA-1-SW (E) I-SB610-YT-BA-1-SW (E) I-SB610-KT-BA-1-SW (E)
