Description
High-Volume Production of Oversized Graphics
This super wide UV-LED printer features seven ink colors, including white, so you can print oversized graphics and panels or simultaneously onto two rolls. It can successfully produce banners, retail displays, wallpaper, and more.
- Maximum print speed of 1,184 SqFt./Hr.
- Layered and dual roll printing with up to six colors and white
- Mimaki Proofing Panel for instant print quality check
- Eco-friendly with low VOC, GREENGUARD Gold certified UV-LED inks
- RIP software RasterLink6 Plus included
Our Core Technologies
 |
Nozzle Check Unit |
 |
Nozzle Recovery System |
 |
Bulk Ink System |
 |
Uninterrupted Ink Supply System |
 |
Mimaki Circulation Technology |
 |
Mimaki Fine Diffusion |
 |
Waveform Control |
 |
Advanced Pass System |
 |
Intelligent Heaters |
Specifications
| Printhead |
Four on-demand piezo heads in a staggered array |
| Print resolution |
300dpi, 600dpi, 900dpi, 1,200dpi |
| Print speed (4 color mode) |
up to 1194.78 SqFt/Hr (111 m2/h) |
| Maximum Print Area |
126″ (3200 mm) |
| Maximum media width |
128″ (3250 mm) |
| Maximum Media Thickness |
up to 0.04″ (1 mm) |
| Maximum Media Weight |
220.7 lbs. (39.10 roll holders) {100 kg (18 roll holders)} |
| Ink Type |
U.S. & Canada- LUS-120 | Mexico, Central & South America- LUS-120 |
| Interface |
Ethernet 1000BASE-T, USB2.0 Hi-speed |
| Power Supply |
Single-phase (AC200 – 240V±10％) 50/60Hz ±1Hz 18A or less |
| Power Consumption |
AC200V: 4.3kW or less |
| Operational Environment |
Temperature 68° – 86° F (20-30° C) |
| Dimensions (W × D × H) |
223.6″ x 48″ x 56.7″ (567.9 mm x 121.9 mm x 144 mm) |
| Weight |
2006 lbs. (910 kg) |
DOWNLOAD BROCHURE, CLICK HERE
| UV curable ink (LUS-120) | Cyan | Magenta | Yellow | Black | Light Cyan | Light Magenta | White | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 1L Bottle | LUS12-C-BA | LUS12-M-BA | LUS12-Y-BA | LUS12-K-BA | LUS12-LC-BA | LUS12-LM-BA | LUS12-W-BA |
