Description
Commercial Print and Cut Capabilities
- Multiple media role handling unit.
- Integrated XY Slitter
- In machine lighting
- V-shaped cut function
- Mimaki Remote Access
- Two staggered heads (6400 nozzles)
Our Core Technologies
Uninterrupted Ink Supply System (UISS)
Variable Dot Technology
Mimaki Bulk Ink System (MBIS)
Mimaki Intelligent Heaters (MIH)
Mimaki Advanced Pass System (MAPS)
APPLICATIONS
SPECIFICATIONS
| Printhead |
On-demand piezo head (2 staggered printheads) |
| Print Resolutions |
600dpi, 800 dpi, 900dpi, 1200dpi |
| Print Speed (4 Color Mode) |
up to 1076.4 SqFt/Hr (100.00 m2/h) |
| Maximum Print Area |
53.5″ (1360 mm) | 63.4″ (1610 mm) |
| Maximum media width |
53.9″ (1370 mm) | 63.8″ (1620 mm) |
| Maximum Media Thickness |
up to 0.04″ (1.0 mm) |
| Maximum Media Weight |
One roll：Max. 45 kg (99.2 lb) or less |
| Ink Type |
Eco-solvent ink |
| Interface |
Ethernet 1000 BASE-T (Recommended) / USB2.0 Hi-speed |
| Power Supply |
Main unit：(Single phase AC100-120/200-240V±10％, 50/60Hz±1Hz) ×2 |
| Power Consumption |
Max. 1,440 W or less x 2 / Min. 4.5 W or less (Sleep mode) |
| Operational Environment |
Temperature: 20–30 °C (68–86 °F) |
| Dimensions (W × D × H) |
2,920 × 1,215 × 1,305 mm (115.0 x 47.8 x 51.4″) | 3,170 × 1,215 × 1,305 mm (124.8 x 47.8 x 51.4″) |
| Weight |
363 kg (800.3 lb.) | 373 kg (822.3 lb.) |
| Certifications |
VCCI class A, FCC class A, ETL IEC 62368-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, REACH, Energy Star, RCM, EAC, KC, UKCA |
| Cutting Speed |
Max. 300 mm/s |
| Solvent Ink (SS21) | Cyan | Magenta | Yellow | Black | Light Cyan | Light Magenta | Orange | Black | White (500mL) |
|---|---|---|---|---|---|---|---|---|---|
| 2L Ink Pack | SPC-0588C | SPC-0588M | SPC-0588Y | SPC-0588K | SPC-0588LC | SPC-0588LM | SPC-0588OR | SPC-0588LK | SS21-W-50 |
