Mimaki CJV150 Series (Print & Cut)

Prix:
$9,445.00 USD
When product is not in stock, usually the time to process is 5-7 days.

Description

Exceptional Output to Meet Your Needs

The CJV150 Series is a highly versatile printer that can employ eco-solvent or dye sublimation inks to complete various application requirements. This high-precision machine accommodates production printing of all kinds.
  • Available in 31.9”, 53.6”, and 64” with print speeds up to 605 Sq.Ft/Hr.
  • Choice of eco-solvent ink or dye-sublimation ink sets
    • Eco-solvent: 8 color options, including Silver, White, Orange, and Light Black inks
    • Dye-sublimation: 6 color options, including Light Blue and Light Magenta inks
  • Optional economic 2-liter bulk ink system for long-running jobs
  • Even ink drying with a three-way intelligent heater
  • Incorporates Mimaki’s proprietary technologies to optimize the use of standard and specialty colors
  • RIP software RasterLink6 included.





Our Core Technologies

img  Mimaki Fine Diffusion
img Half Cut
img Over Cut
img Zero Margin Mark
img Continuous Mark Detect
img Waveform Control
img Mimaki Advanced Pass System
img Mimaki Intelligent Heaters
img Nozzle Check Unit
img Nozzle Recovery System
img Mimaki Bulk Ink System
img Uninterrupted Ink Supply System
img Uninterrupted Ink Supply System



APPLICATIONS

girl wearing t-shirt with custom new york city design
Custom Mimaki Microfactory Tailgate Logo
flexible printed advertisements on store shelves



The CJV150 Series prints on a range of media, including polyester materials. It is suited for retail graphics, signage, fabric printing, t-shirt graphics, product containers, cosmetic products, and more.

Specifications

Printhead

One on-demand piezo head
Print resolution

360 dpi, 540 dpi, 720 dpi, 1,080 dpi, and 1,440 dpi
Print speed (4 color mode)

CJV150-75: 432.7 SqFt/Hr (40.2 SqM/Hr)
CJV150-107: 488.7 SqFt/Hr (45.4 SqM/Hr)
CJV150-130: 526 SqFt/Hr (48.9 SqM/Hr)
CJV150-160: 604.9 SqFt/Hr (56.2 SqM/Hr)
Maximum Print Area

CJV150-75: 31.5 in (800 mm)
CJV150-107: 42.9 in (1,090 mm)
CJV150-130: 53.6 in (1,361 mm)
CJV150-160: 63.4 in (1,610 mm)
Maximum media width

CJV150-75: 31.9 in (810 mm)
CJV150-107: 43.3 in (1,100 mm)
CJV150-130: 54 in (1,371 mm)
CJV150-160: 63.8 in (1,620 mm)
Maximum Media Thickness

up to 0.04″ (1 mm)
Maximum Media Weight

88.2 lbs. (40.0 kg)
Ink Type

U.S. & Canada- SS21, ES3, Sb53, Sb54 | Mexico, Central & South America- SS21, ES3, BS3, BS4, Sb53, Sb54
Cut Speed

16.5″ sec (42 cm/sec)
Maximum Cut pressure (Metric grams)

450
Cutter Types

Eccentric cutter, Blade for the small character, Blade for reflective sheet, Blade for fluorescent sheet, Blade for PVC with low-pressure, Ballpoint pen
Interface

USB 2.0 Hi-speed (Ethernet 1000 BASE-T for E-mail notification function)
Power Supply

CJV150-75: Single-phase (AC 100–120V / AC 220–240V)
Power Consumption

100V:1.44 kVA × 1 or less / 200V: 1.92 kVA × 1 or less
Operational Environment

Temperature 68° – 86° F (20-30° C)
Humidity: 35–65 % RH (Noncondensing)
Dimensions (W × D × H)

CJV150-75: 77″ x 28″ x 55″ (195.6 x 71.1 x 139.7 mm)
CJV150-107: 89″ x 28″ x 55″ (226.1 x 71.1 x 139.7 mm)
CJV150-130: 99″ x 28″ x 55″ (251.5 x 71.1 x 139.7 mm)
CJV150-160: 109″ x 28″ x 55″ (276.9 x 71.1 x 139.7 mm)
Weight

CJV150-75: 278 lbs. (126 kg)
CJV150-107: 313 lbs. (142 kg)
CJV150-130: 346 lbs. (157 kg)
CJV150-160: 370 lbs. (168 kg)
Certifications

CJV150-75:
VCCI class A, FCC class A, ETL UL 60950-1
CE Marking (EMC, Low voltage, Machinery directive, and RoHS),
CB, REACH, Energy Star, RCM

DOWNLOAD THE CJV150 BROCHURE, CLICK HERE

Solvent ink (SS21) Cyan Magenta Yellow Black Light Cyan Light Magenta Light Black Orange White Silver
2L MBIS Pack* SPC-0588C SPC-0588M SPC-0588Y SPC-0588K SPC-0588LC SPC-0588LM SPC-0588LK SPC-0588OR
440ml cartridge SPC-0501C SPC-0501M SPC-0501Y SPC-0501K SPC-0501K SPC-0501LM SPC-0501LK SPC-0501OR
220ml cartridge SPC-0504W-2 SPC-0504Si

*Inks sold vary by county; see the specification chart above for details.

Eco Solvent ink (ES3) Cyan Magenta Yellow Black Light Cyan Light Magenta
440ml cartridge SPC-0440C SPC-0440M SPC-0440Y SPC-0440K SPC-0440LC SPC-0440LM
220ml cartridge SPC-0433W-2



Dye Sublimation ink (Sb54) Blue Magenta Yellow Black Light Blue Light Magenta
2L MBIS Pack* SB54-BLT-2L SB54-MT-2L SB54-YT-2L SB54-KT-2L SB54-LBT-2L SB54-LMT-2L
440ml cartridge SB54-BLT-44 SB54-M-44 SB43-Y-44 SB54-K-44 SB54-LBL-44 SB54-LMT-44

*Inks sold vary by county; see the specification chart above for details.

Dye Sublimation ink (Sb53) Blue Magenta Yellow Black Light Blue Light Magenta Deep Black
2L MBIS Pack* SB53-BL-2L SB53-MT-2L SB53-Y-2L SB53-K-2L SB53-LBL-2L SB53-LM-2L SB53-DK-2L
440ml cartridge SB53-BL-44 SB53-M-44 SB53-Y-44 SB53-K-44 SB53-LBL-44 SB53-LM-44 SB53-DK-44



Solvent ink (BS3) Cyan Magenta Yellow Black
2L MBIS Pack* SPC-0693C SPC-0693M SPC-0693Y SPC-0693K
600ml cartridge SPC-0667C SPC-0667M SPC-0667Y SPC-0667K

*Inks sold vary by county; see the specification chart above for details.

Solvent ink (BS4) Cyan Magenta Yellow Black
2L MBIS Pack* BS4-C-2L BS4-M-2L BS4-Y-2L BS4-K-2L
600ml cartridge BS4-C-60 BS4-M-60 BS4-Y-60 BS4-K-60
