Descrizione
Superior Finishing for Any Application
This heat-assisted device improves laminate film adhesion, particularly to surfaces printed with UV-LED ink, and reduces the potential for the silvering effect created by pressure-sensitive laminates.
- 62.2” maximum width.
- Fast throughput speeds and easy to use.
- Easy access to pressure handle and foot pedal.
- The take-up reel makes it easy for one person to operate the entire process.
- Designed to use with Mimaki Vision Laminate film and any of our roll-to-roll printers.
Specifications
| Maximum processing width |
62.2″ (1,580 mm) |
| Roller diameter |
4.72″ (120 mm) |
| Processing thickness |
1.38″ (35 mm max.) |
| Processing temperature |
From room temperature to 60 °C (140 °F) |
| Processing speed |
0 to 295.3″ min (0 to 7500 mm/min) |
| Core diameter |
Three inches |
| Power |
USA: 120V | EU: 230V | other: 100V |
| Rated current |
USA: 14A | EU: 8A | other: 15A |
| Power consumption |
1800W or less |
| Preheating time |
About 30 minutes |
| Pedal switch |
One |
| Attachment shaft (with measure scale) |
3″ x 5 pcs. |
| Dimensions (W×D×H) |
78.7″ x 21.7″ x 50.4″ (2,000 x 550 x 1,280 mm) |
| Weight |
451.9 lbs. (205 kg) |
